KUBOTA VS600-VS750 SPREADERS

KUBOTA VS600-VS750 SPREADERS
Popular for General Farm Applications

The Kubota pendulum spreader is the first choice wherever the demand is for maximum spreading quality and ease of operation. With hopper capacities of 600, 800 and 1000 with the 600 hopper as a basic hopper and 750, 950, 1150, 1350 and 1650 litres with the 750 as a basic hopper, Kubota is offering you a wide range of different models and hopper capacities. Spreading along field edges and tram line border spreading is no problem at all – thanks to the border spreading plate and the tiltable headstock.

The standard working width of the VS spreader range is 1 up to 14 metres. When you increase the PTO speed of the tractor from 540 rpm to 620 rpm the working width can be increased to 15 metres. VS spreaders feature exact rate control, quick change spouts, low filling heights and easy maintenance.
Technical specifications

VS
VS600
VS800
VS1000

Hopper capacity (l)
600
800
1000

Hopper width (cm)
175
175
175

Filling height (cm)
96
106
116

Weight 3-point types (kg)
130
155
165

PTO speed (rpm/min)
540
540
540

Three-point linkage category
2
2
2

VS
VS750
VS950
VS1150
VS1350
VS1650
Hopper capacity (l)
750
P950
1150
1350
1650
Hopper width (cm)
175
175
175
175
175
Filling height (cm)
96
106
116
125
141
Weight 3-point types (kg)
151
158
171
178
184
PTO speed (rpm/min)
540
540
540
540
540
Three-point linkage category
2
2
2
2
2

Optional Equipment

Lighting set
For all VS spreaders an optional lighting set is available. Reflector decals are available for safe transport.
Fine application kit
Shuts two of the three openings of the metering device for the application of small quantities of fine seeds.
Pivoting wheels
This set of pivoting wheels allows the spreader to be easily moved when detached from the tractor.
Agitator
The agitator ensures an even material feed to the spreading unit. A safety grid protects the agitator.
Grid
A grid fitted inside the hopper prevents lumps of fertiliser penetrating the feed mechanism.
Fine application kit
Shuts two of the three openings of the metering device for the application of small quantities of fine seeds.
Calibration container
Allows calibration tests to be performed with spout in place.
Hopper extensions
To increase hopper capacity, 100, 110, 200, 300, 600 and 900 litre hopper extensions are available (varies by model).
Hydraulic remote control
Allows the metering disc to be opened and closed from the driver’s seat (one single acting control valve required).
